All AIAIAI transmitters are designed to provide a cable-free, ultra-low latency audio experience using W+ Link technology. Each transmitter is bundled with compatible wireless products to ensure seamless setup.
In this article goes through the transmitters compatibilities, and each transmitters product manual.
Jump to section:
· Transmitter compatibility overview
· Product Manual - X01 Transmitter
· Product Manual - X02 Transmitter
· Product Manual - X03 Transmitter
· Product Manuals - PDF download
Transmitter compatibility overview
This chart explains which AIAIAI transmitters (X01, X02, X03) work with which products and how many devices you can connect simultaneously.
| Transmitter | Compatible products | Included in | Key features |
| X01 | H10 Headband | TMA-2 Studio Wireless+ H10 X01 Bundle | Battery powered Audio input via mini-jack |
| X02 | H10 Headband UNIT-4 Studio Monitor | UNIT-4 Wireless+ Studio Monitor | USB-C Powered Audio input via USB-C and mini jack Can connect to 2 devices simultaneously |
| X03 | S11 Speaker units | TMA-2 DJ Wireless TMA-2 Studio Wireless | Battery powered Audio input via TRS line in or USB-C |
Compatible with H10 Headband
General
Power on: Push button (3 sec).
Power off: Push button (3 sec).
Enter pairing mode: Double push button (power on).
Hard reset device: Push button (7 sec).
LED FEEDBACK
State | LED |
General | |
Power on | Solid light (3 sec) matching battery level: |
Turned on, idle and no link | Blinking LED 1, (1 sec on, 1 sec off) |
Turned on, idle and linked to H10 | Solid light LED 1 |
Power off | No feedback |
Enter pairing mode | All LEDs blinking (300 ms on, 300 ms off) loop |
Reset pairing mode | No function |
Hard reset device | 5 short flashes on all LEDs (< 0.5 sec on < 0.5 sec off) |
LED battery level indicator
<25% battery: LED one flashes.
25-50% battery: LED one-two static.
50-75%: LED one-two-three static.
75-100%: All LEDs static.
Compatible with H10 Headband + UNIT-4 Studio Monitor
General
Connecting to audio using USB-C: X02 will power on when connected
Connecting to audio using 3.5mm mini-jack:
Connect the USB-C socket to a 5V/>2A adapter (for example a phone charger or power bank).
Connect to audio
Connect to your audio source using the USB-C or 3.5mm mini-jack sockets on X02.
Pairing
First put the device(s) you wish to connect to in pairing mode.
The first time X02 is powered on, it will start in pairing mode automatically.
LED 1 is solid white when the first device pairs. If you have a second device, LED 2 is solid white when it pairs.
To enter pairing mode manually, hold the button on X02 for 2 sec.
Compatible with S11 Speaker unit
Button Functions
Turn on X03: Hold the button for 2 seconds, until the LED turns on.
Turn off X03: Hold the button for 2 seconds, until the LED turns off.
Check battery level: Push the button once.
Red: <10 hours.
Amber: 10-20 hours.
Green: 20+ hours.
Enter pairing mode: With power off, hold the button for 4 sec, until the LED starts flashing fast.
Reset S11 paired devices: With power off, hold the button for 8 sec. The LED will flash fast when reset.
LED FEEDBACK
State | LED Feedback |
Not paired (Idle mode) | LED flashing white (1 sec on, 1 sec off, loop) |
Pairing mode | LED flashing white (0.3 sec on, 0.3 sec off, loop) |
Paired | Constant white |
Reset paired device list | LED flashing fast 5 times (0.1 sec on, 0.1 sec off) |
Battery status (power on) | Push the control button. Battery is displayed for 3 sec. 20 - 40 hours - Constant green 10 - 20 hours - Constant amber 3 - 10 hours - Constant red 0 - 3 hours - Flashing red (0.3 sec on, 0.3 sec off) |
Low battery indicator (power on) | Flashing red (0.3 sec on, 0.3 sec off) |
Charging (power on) | Battery status is shown for 3 sec after USB-C charger connected Check battery status by pressing the button |
Charging (power off) | Fully charged - Constant green 20 - 40 hours - Flashing green (1 sec on, 1 sec off) 10 - 20 hours - Flashing amber (1 sec on, 1 sec off) 0 - 10 hours - Flashing red (1 sec on, 1 sec off) |
Product Manuals - PDF Download
