X01 transmitter
General
Power on: Push button (3 sec).
Power off: Push button (3 sec).
Enter pairing mode: Double push button (power on).
Hard reset device: Push button (7 sec).
LED FEEDBACK
State | LED |
General | |
Power on | Solid light (3 sec) matching battery level: |
Turned on, idle and no link | Blinking LED 1, (1 sec on, 1 sec off) |
Turned on, idle and linked to H10 | Solid light LED 1 |
Power off | No feedback |
Enter pairing mode | All LEDs blinking (300 ms on, 300 ms off) loop |
Reset pairing mode | No function |
Hard reset device | 5 short flashes on all LEDs (< 0.5 sec on < 0.5 sec off) |
LED battery level indicator
<25% battery: LED one flashes.
25-50% battery: LED one-two static.
50-75%: LED one-two-three static.
75-100%: All LEDs static.
